Sirius NDR Portable Compact Four 2port 1/10GbE 25Gbps, 6/ 12TB
 |
||
|---|---|---|
| Model | Portable Compact 2.5in SSD | |
| Model | NDR-PC1SN1-2XG-B4-6T/-12T | |
| Media Interface | Model: 10G-A2 x 1 (2XG) Specifications: SFP/SFP+ x 2 10Base-T 100Base-TX 1000BASE-SX/-LX/-T 10Gbase-SR/-LR/-T |
|
| CPU | Intel Multicore Single CPU | |
| Memory | 128 GB | |
| Capture Storage (TB) | 6/ 12TB | |
| Capture Storage Performance | 25 Gbps (25Gx1 line rate configurable) (when in RAID5) |
|
| Timestamp Granularity | 3.2 ns | |
| Timestamp Accuracy | within 20 ns Equipped with PPS interface for external synchronization | |
| Capture Packet Size | 64 ~ 10000 Bytes | |
| RAID | RAID5 | |
| Dimension(w x h x d) | 155 x 266(+49*) x 315 (mm) *With carrying knob attached 8 Kg (Built-in AC power supply) |
|
| Power | Voltage: AC 100V ~ 240V Wattage: ~750W |
|
| interface | USB 3.0 Type-A 2 ports, USB 2.0 Type-A 2 ports, VGA port | |
| Accessories | soft bag, USB mouse, mobile display, mini USB keyboard | |
| The above is only an example configuration. The chassis can be fitted with different storage capacities and/or media interfaces. For more information, please feel free to contact us. | ||
